Product Feature
It can realize the data collection of three-phase electric or single-phase electric current (three-way), voltage (three-way), active power, reactive power, power factor, temperature, etc.; It has 1~8 way loop switch control.
The timing policy delivered by the receiving server is stored locally, and the data to be queried by the server is reported; local or remote query and configuration can be implemented; at the same time, policy query and modification can be implemented; manual real-time control commands and query commands can also be performed.
Loop control: With 4/8 loop control output, the default is 4 loop output.
Timing control: With multi-level timing control, the timing can be modified locally and remotely.
Longitude and latitude control: with automatic control of latitude and longitude.
Abnormal condition buzzer alarm (You can set the upper limit and lower limit of the alarm yourself, and query for alarm when there is abnormal data information)
LCD display (can choose the information you want to display), color screen with backlight
Button selection control (convenient configuration, menu selection query view information, select send control command)
Spare lithium battery (3.6V, 80Mah)
Device reference voltage detection (low voltage detection)
Status signal indicator (Reaction subnet controller real-time working status)
Intelligent function: automatically combines various sensors (temperature, rain, snow, light) to automatically analyze local weather conditions and environmental conditions to automatically control the light switch and brightness.
Reserved function: SMS abnormal data alarm; smart phone through the APP, to achieve the monitoring of the lights.
Product parameters
Power consumption | 3.7W | SIM card voltage | 3V，1.8V |
Power supply | Three phase | single phase | | Transmission rate | Downstream maximum: 85.6Kbps Upstream maximum: 42.8Kbps |
Wireless frequency band | 2.4G | Communication Interface | ZIGBEE, GPRS, RJ-NET optional |
Acquisition parameter | U,I.P.Q.T | Sensor access | Rain and snow, light, traffic flow, switching, 4-20MA, 0-5V, etc. |
Communication Interface | GPRS\CDMA | Single network capacity | 0 to 500 nodes |
Product Size | 285cm*179cm*96cm | ZIGBEECommunication distance | Line of sight 2000M between single points |
shell | ABS | Protocol | Shunzhou private, modbus, State Grid meter 97, 07 statute |
Loop switch | 8 roads\4 roads | Meter access | Support the access of State Grid Smart Meter 485 port |
ARM | High performance 32-bit ARM processor | Antenna gain | 1DB |
Lightning protection level | Anti-surge 6000V single phase | Antenna interface | SMA male |
range of working temperature | －40℃～＋75℃（Industrial grade） | Antenna standing wave | 《1.5 |
