Multi-functional Gateway

‍‍

Product Description

SZ11-GW-6 is a kind of Internet of Things wireless communication gateway, which uses the public network wireless network + LoRa network to provide users with the function of eliminating the need of field wiring and wireless long-distance data transmission.

The product uses high-performance industrial 32-bit processor and industrial-grade wireless communication module, while providing 1x serial port (RS485), 1x USB2.0 port, 3x Ethernet LAN ports, 1x Ethernet WAN port. The 3 LAN ports support PSE function, 802.3AT standard, and the maximum power output of a single port is 30W. Modular hardware is used inside, which can quickly adapt to different hardware according to different user needs.

It can be connected to serial devices, Ethernet devices and Wi-Fi devices at the same time, which provides a perfect platform for IoT applications. A 3TOPS computing power card is optional to be assembled. And the system is open, users can install Docker images or video analysis algorithms by themselves.

SZ11-GW-6 gateway can be widely used in industries such as self-service terminal industry, smart grid, intelligent transportation, supply chain automation, industry automation, intelligent building, fire protection, environmental protection, smart medical treatment, smart lighting, smart agriculture and coal mines, oil and other occasions.

Functions and Features

● Support 4G/5G, Ethernet port access to the Internet, multi-network at the same time online;

● 10/100/1000Mbps WAN port x1, 10/100/1000Mbps LAN port x3;

● Stable full Netcom speed experience, fully compatible with major operators’ 3G/4G/5G network (4G module or 5G module can be selected according to requirements, 4G module supports 3G/4G communication, 5G module supports 3G/4G/5G communication);

● Wired and wireless backup each other to ensure normal and stable data transmission, multi-network intelligent switching backup, data storage when the network is disconnected, and data transmission resume after network recovery;

● Optional LoRaWAN frequency bands: CN470MHz, IN865MHz, EU868MHz, RU868MHz, US915MHz, AU915MHz, AS923MHz, KR923MHz;

● Support Zigbee master station (2.4GHz global free frequency band);

● Rich protocol, support transparent transmission, MODBUS RTU switch TCP and MQTT;

● Support active polling of Modbus RTU devices, support configuration of protocol analysis templates, help users save the input of tedious SCADA Modbus commands, and at the same time complete protocol analysis and conversion, directly report to the platform, reducing protocol conversion.

● Support optional NPU computing power card, 3TOPS computing power, open system, users can install Docker image or video analysis algorithm by themselves, widely used in edge computing scenarios.

● Industrial Design, Metal Case, Stable 7x24 Hours Uninterrupted Work Under Various Industrial Environments & Strong Interference.

● Standard DIN35 rail installation, also supports wall-mounted installation, suitable for different application scenarios.
